Austral Piston Set - PO1311TLA STD
Details
https://www.supercheapauto.com.au/p/austral-isuzu-4jb1t-late-piston-set---alfin/SPO1200500.html
$414.00
$0.00
Promotions
Special Offer
Only select SCA stores can do fitments, please enter your location to see the closest.
Item No. SPO1200500
Additional Information
Tech Spec
ISUZU 4JB1T (Late) 'PISTON SET - ALFIN'
Head Type | Dish Top with 2 Valve Reliefs |
---|---|
Bowl Dia. | 44.00mm |
Bowl Depth | 19.30mm |
Top Of Combustion Bowl Mound to Piston Crown | 7.90mm |
Compression Height | 52.00mm |
Overall Length | 92.00mm |
Pin Size | 34.00mm x 78.00mm |
Pin Type | Full Floating |
Top Ring Width | 2.00mm |
Second Compression Ring Width | 2.00mm |
Oil Ring Width | 4.00mm |
Use Ring Set | BR1310 STD |
